RATING or WARRANTY PLATE and CERTIFICATION LABEL - continued

ASSEMBLY PLANT CODES

1964/65 U.S. BUILT VEHICLES
1966/ U.S. and CANADIAN BUILT VEHICLES

THE FIFTH DIGIT OF THE WARRANTY OR VEHICLE IDENTIFICATION
NUMBER INDICATES  THE PLANT AT WHICH THE VEHICLE WAS
ASSEMBLED. THE FOLLOWING CHART LISTS THESE CODES
AND THE CORRESPONDING ASSEMBLY PLANT.


CODE ASSEMBLY PLANT CODE ASSEMBLY PLANT
C Ontario Truck L Michigan Truck
D Dallas N Norfolk
E Mahwah P Twin Cities
G Chicago R San Jose
H Lorain S Pilot Plant (Allen Park)
K Kansas City U Louisville
V Kentucky Truck




NUMERICAL SEQUENCE OF ASSEMBLY

1964/65 U.S. BUILT VEHICLES
1966/ U.S. and CANADIAN BUILT VEHICLES

A PRODUCTION SERIAL NUMBER SYSTEM IS USED TO IDENTIFY MODEL YEARS.
THE FOLLOWING CHART LISTS THE SERIAL NUMBER RANGES AND THE MODEL
YEAR REPRESENTED DEPENDENT ON THE MODELS LISTED.

SEQUENCED IN ORDER OF SERIAL NUMBER
FROM SERIAL
NUMBER		 TO SERIAL
NUMBER		 MODEL CATALOGED AS
MODEL YEAR
(CANADIAN BUILT VEHICLES)
150,001   C-CT700/1100, F800/1100, T700/950 1965
195,001   B500/750, C550/600, E-F-P100/750 1965
(U.S. BUILT VEHICLES)
445,001 580,000 B-E-F-P100/600 1964
465,001 580,000 B-F-T700/1100, C-CT-H-HT-N-NT500/1100 1964
580,001 732,000 All (exc. F-N-NT-T500/1100 w/raised roof) 1965
(U.S. and CANADIAN BUILT VEHICLES)
713,001 716,000 F-N-NT-T500/1100 - w/raised roof 1966
732,000 914,000 All 1966
A00,001 B82,000 All (exc. E100) 1967
A00,001 B99,999 E100 1967
C00,001 D82,000 All (exc. E100/300) 1968
C70,001 G30,000 E100/300 1969
D82,001 G30,000 B-F-P100/750, C-CT-W-WT550/1000 1969
D82,001 G90,000 F-T800/1000, N-NT500/1000 1969
G30,001 J70,000 B-E-F-P100/750 1970
G30,001 J90,000 C-CT-W-WT500/1000 1970
G90,001 J90,000 L-LN-LNT-LT-LTS500/900 1970
J70,001 M30,000 B-F-P100/750 1971
J90,001 M30,000 C-CT-W-WT500/1000, L-LN-LNT-LT-LTS500/900 1971
K00,001 M30,000 E100/300 1971
M40,001 Q00,000 All 1972

Next page


Symbol (in the text listings or exploded-view diagram) indicates part is not supplied for service due to the following:
          a. Part is superseded and replaced as indicated in the description column of text
          b. Part can be improvised as indicated in the description column of text
          c. Due to it's function there would be little or no demand		 - Identifies unique Canadian part numbers and application and have been and footnoted.
- Identifies unique U.S. part numbers and application and have been footnoted.
  - Site Admin notes (not part of the original MPC)
