Technical Drawings and Schematics - Section F
Heating / Cooling / Air-Conditioning

Air Conditioning Parts, Passenger Compartment
1968-1972 F100-F350 - w/integral A/C

1500 x 996, 321K

Air Conditioning Parts - Engine Compartment
1968-1972 F100/350 - 8 cyl. 360, 390 - w/integral A/C

1732x 1200, 364K

Air Conditioning Hoses, Engine Compartment
1968-1972 F100-F350 - 6-cyl. 240, 300 - w/integral A/C

1616 x 1200, 332K

Air Conditioning Hoses (Engine Compartment)
1968-1972 F100-F350 - w/integral A/C

1200 x 1659, 332K

1972 factory underdash A/C system

1146 x 844, 170K

Air Conditioning Parts - Passenger Compartment
1965-1969 F100/250 - 6 Cyl. 240 and 8 Cyl. 352 w/Hang-On A/C

1417 x 1024, 283K

Air Conditioner Evaporator Parts (Passenger Compartment)
1966-1972 F100/250 - Deluxe and Economy Hang-On
1969-1972 E100/300 - Built-In A/C (Dealer Installed)

1024 x 1465, 149K

Air Conditioner Deluxe Hang-On Bezel and Controls (Passenger Compartment)
1968-1972 F100/250

1608 x 1024, 138K

Air Conditioner Economy Hang-On Bezel and Controls (Passenger Compartment)
1968-1972 F100/250

1440 x 1024, 147K

Compressor - Air Conditioner (Techumseh Design - Cast Iron)
1964-1972 All

1440 x 1024, 147K

Compressor - Air Conditioner (York Design - Aluminum)
1964-1972 All

1024 x 1238, 138K

Air Conditioner Parts (Engine Compartment)
1968 F100/250 - 6 Cyl. 240, 300 - w/ Hang-On A/C)
1969-1972 E100/300 - Built-In A/C (Dealer Installed)

1024 x 1474, 223K

Air Conditioner Parts (Engine Compartment)
1968-1972 F100/250 - 8 Cyl. 302 - w/ Hang-On A/C

1025 x 1428, 225K

Heater Parts, Fresh Air
1965-1972 F-N-NT-T100/1100 (exc. NH diesel)

1486 x 1024, 339K

Cooling System and Related Parts - Typical
1965-1972
F100/350 - 6 Cylinder 240, 300

900 x 1156, 164K

Cooling System and Related Parts - Typical
1964-1972 B-F-N100/750 - 8 Cylinder 330, 352, 360, 361, 390, 391

1200 x 947, 180K

Coolant Recovery System and Related Parts
1971/72 F100/250 - 6 Cylinder 240, 300

900 x 790, 96K
